Description
Features：
* Remote controlling integrator, specially designed for waste water treatment.
* Highly integration and space saving
* Simple equipping flow and easy for maintenance
* Mainboard with 3-paintings and suitable for various environment.
* Remote controlling integrator, specially designed for waste water treatment.
* Highly integration and space saving
* Simple equipping flow and easy for maintenance
* Mainboard with 3-paintings and suitable for various environment.
| Hardware： | |
| CPU | 300MHz ARM9 |
| Memory | 128MB Flash+64MB DDR2 |
| Wireless Communication | Mobile 2G/Unicom 2G |
| Spare Battery | Alarming when the electricty disconnected |
| Position | Base Position |
| Local Storage | Store 50000 historical items |
| Remote Upgrading | Program remote upgrading, parameters remote equip |
| 3rd Connection | HTTP/SDK connection |
| Electrical Specifications： | |
| Input Power | DC 24V,Input Range:DC 18V～28V |
| Power Consumption | < 5W |
| Power Protection | Protected from thunderstrike and surging |
| Power Down Allowed | < 500mS |
| CE & RoHS | EN61000-6-2:2005, EN61000-6-4:2007, RoHS, CE Surge Immunity:±1KV；EFT:±2KV; ESD:4KV, Air:8KV |
| Environment Specifications： | |
| Operating Temperature | -20～70°C |
| Storage Temperature | -30～80°C |
| Operating Humidity | 10～90%RH(No condensation) |
| Vibration Endurance | 10～25Hz(X/Y/Z 2G/30Min) |
| Cooling | Natural cooling |
| Performance： | |
| Digital Input | 2-line DI input（connection input）such as liquid level floating ball and gate magnetism |
| Analog Input | 1-line 4-20mA input，used for water quality testing sensor |
| Digital Output | 2-line DO output（220V,5A relay output） Build-in 2-line electricity testing, accuracy 10mA, ontime electricicty monitoring |
| Timer | 10*2 lines |
| Communication Protocol | 1-line RS485, using for connecting electricity gauge |
| Others： | |
| Degree of Protection | IP20 |
| Dimension | 160mm x 99mm x30.5mm |
| Weight | About 530g |
